ABB 3BHB020720R0002 | 5SHY3545L0016 IGCT Module

In stock

This ABB IGCT module is designed for high-voltage drive systems, offering superior efficiency and reliability in industrial applications.

Brand:ABB

Model Number:3BHB020720R0002 5SHY3545L0016

Module Type:IGCT Module

Operating Voltage:Range: 6.6 kV to 12 kV

Maximum Current:Up to 5,000 A

Switching Frequency:50 kHz

Cooling System:Water-cooled

Dimensions (LxWxH):1050mm x 300mm x 350mm

Weight:Approx. 120 kg

Insulation Class:Class F

Certification:UL/IEC/EN compliant

    The ABB 3BHB020720R0002 – 5SHY3545L0016 IGCT MODULE is specifically engineered to optimize performance in high-demand industrial environments. This state-of-the-art module ensures reliable and efficient power management, essential for maintaining optimal operational conditions in industries ranging from manufacturing to renewable energy sectors.

    With its robust design and advanced technology, this IGCT module is capable of handling high currents and switching frequencies, making it suitable for applications requiring precise control over electrical power. Its wide operating temperature range (-40°C to +70°C) guarantees reliability across various geographical locations.

    Featuring a 16-pin TO-220 package, the module is compact yet durable, offering excellent heat dissipation properties to maintain optimal performance even under high-load conditions. The high insulation resistance and electrical insulation voltage ensure safety and reliability, surpassing industry standards.

    Engineered with attention to environmental considerations, the ABB IGCT module complies with RoHS and REACH regulations, promoting sustainable industrial practices. It is designed for longevity, with a mechanical life exceeding 1 million switching cycles, ensuring minimal maintenance requirements and extended operational life.

    For businesses seeking to enhance their energy efficiency and operational reliability, the ABB 3BHB020720R0002 – 5SHY3545L0016 IGCT MODULE is the ideal choice. Its advanced features and proven performance make it a cornerstone in modern industrial power management systems.

ABB 3BHB020720R0002 5SHY3545L0016 IGCT MODULE
